TRAILER
BY3006
BALL MOUNT - 2" SHANK
• Straight, high-low and deep drop tube style ball mounts
• Fits 2" receiver tubes
• Two piece welded steel construction
• Tongue accepts 1" diameter shank towing balls
• Available in stainless steel, chrome plated or black powder coat finish
• 6000 M.G.T.W., 600 lbs Maximum Vertical Load
DESCRIPTION
LENGTH
MAX
DROP
PART #
Straight Ball Mount
8"
2"
BY3005
16.75
G
Straight Ball Mount Chrome
Plated
8"
2"
BY3006
24.60
G
Straight Ball Mount
10"
2"
BY3007
20.30
G
High-Low Ball Mount
8"
4"
BY3010
20.70
H
High-Low Ball Mount Chrome
Plated
8"
4"
BY3011
25.80
H
High-Low Ball Mount
10"
4"
BY3013
23.65
G
Deep Drop Ball Mount
10"
6"
BY3015
27.60
G
Deep Drop Ball Mount Chrome
Plated
10"
6"
BY3016
34.30
G
Deep Drop Ball Mount
10"
8"
BY3017
30.35
G
Deep Drop Ball Mount Solid
Shank
10.28"
10 1/4"
BY3019 *
58.60
G
M. V. L. = MAXIMUM VERTICAL LOAD M. G. T. W. = MAXIMUM GROSS TOWINGWEIGHT
* Note: M.V.L. 350#
• M.G.T.W. 5,000#
BY3005
BY3007
BALL MOUNT - 1-1/4" SHANK
• Fits 1-1/4" receiver tubes
• Solid steel construction
• Black powder coat finish for durability & corrosion resistance
• Tongue accepts 3/4" diameter shank towing balls
• 3500 M.G.T.W., 300 lbs Maximum Vertical Load
LENGTH
MAX
DROP
PART #
9"
1 1/4"
BY3100 20.55
G
7"
2 1/2"
BY3105 20.55
G
7"
4"
BY3110 21.45
G
BY3110
BY3105
RISE DROP LENGTH DIAMETER M.G.T.W.
PART #
1-1/2"
3” Drop
9-3/4"
1-1/4" Hole 14,000#
444073 82.99
G
3-1/2"
5” Drop
10"
1-1/4” Hole 13,000#
444074 73.40
G
-----
7-3/4" Drop 10-1/2" 1-1/4" Hole 13,000#
444075* 99.87
G
1-1/2"
3” Drop
10"
1-1/4” Hole 18,000#
444076 85.74
G
3-1/2"
5" Drop
10"
1-1/4" Hole
18,000#
444077 93.48
G
* Note: Use in Drop Position Only
• 2-1/2" square design for use with Titan Hitches
• Ideal for marine, agricultural and recreational use
• Black powder coat finish
BALL MOUNT - 2-1/2"
SQUARE SHANK FOR USE
WITH TITAN HITCHES
444073
444074
444077
444076
444075
