HITCHES
68
tires &
wheels
axles, hubs
& springs
tongue
accessories
hitches
electrical
brake
parts
trailer
hardware
locks &
pins
towing &
loading
tie downs
tools
chemicals
TRAILER
ADJUSTABLE TRI-BALL MOUNT - CHROME
• 1-7/8", 2", 2-5/16" balls
• Solid shank for 2" receiver tubes, welded steel towing balls, black powder coat
finish, and a 5/8" hitch pin hole
• Individually boxed for shipping
• All three towing ball sizes (1-7/8", 2" and 2-5/16") on one solid shank
• 12" vertical adjustment
ADJUSTABLE BALL MOUNT -
3 POSITIONS
ADJUSTABLE BALL MOUNT -
4 POSITIONS
• Fits 2" receiver tubes
• Welded steel construction
• Black powder coated finish
• Fits 2" receiver tubes
• Welded steel construction
• Black powder coated finish
ADJUSTABLE TRI-BALL MOUNT
M. V. L. = MAXIMUM VERTICAL LOAD M. G. T. W. = MAXIMUM GROSS TOWINGWEIGHT
• 3 1" mount holes
• 1 1/4" accessory hole
• 6 different height positions
• 16 different hitch configurations
• 6 vertical adjustments
• Quick single pin adjustments
LENGTH MAX DROP MAX LIFT M.V.L M.G.T.W. WEIGHT
PART #
16-1/2"
6"
6"
1,200# 20,000# 17#
BY2310 176.95
B
MAX DROP MAX LIFT M.V.L M.G.T.W.
PART #
8"
6-3/4"
600#
6,000#
BY3093 67.75
G
MAX DROP MAX LIFT M.V.L M.G.T.W.
PART #
11"
9-3/4"
600# 6,000#
BY3090 66.95
H
BY2225 213.95
E
TRI-BALL MOUNT WITH PINTLE HOOK
• Features 3 towing balls and a pintle hook on 1 solid steel shank
• Black powder coated shank fits 2" receivers
• 5/8" Hitch Pin hole
• 1-7/8", 2", 2-5/16" welded steel tubing ball
• 7500# cast steel pintle jaw
• Upper jaw locks in the open (up) position for coupler towing
• Upper jaw locks in the closed (down) position for lunette eye towing
CAPACITY
1-7/8" Ball
6,000 lbs M.G.T.W.
2" Ball
7,500 lbs M.G.T.W.
2-5/16" Ball
10,000 lbs M.G.T.W.
Pintle cap
7,500 lbs M.G.T.W.
OPEN
CLOSED
BY2279 139.95
H
