BY8520 6.95
G
• Drop forged combination pintle hook/ball hitch
• Forged steel ball
• Interchangeable hitch balls
• Finished with black powder coat for superior durability and corrosion resistance
• Capacity: 16,000 lbs. M.G.T.W., 3,000# Maximum Vertical Load
• BOLT KIT TO MOUNT IS NOT INCLUDED
• Drawbar eye dimensions: 2-1/2" to 3" ID with 1-1/4" to 1-9/16" diameter section
8-TON FORGED ALLOY STEEL
COMBINATION HITCH
INCLUDES DRILLING TEMPLATE & CAPACITY DECALS
10-TON HITCH - DROP FORGED,
BLACK POWER COAT FINISH
• Capacity: 20,000 lbs. M.G.T.W., 4,000 lbs. Maximum Vertical Load
• Drop forged combination pintle hook/ball hitch
• Forged steel ball
• Interchangeable hitch balls
• Finished with black powder coat for durability and corrosion resistance
• Drawbar eye dimensions: 2-3/8" to 3" up to 1-9/16
cross section
BALL SIZE
PART #
2"
BY10052 152.20
E
2-5/16"
BY10057 151.75
E
BALL SIZE
PART #
2"
BY2000 28.90
G
2-5/16"
BY2516 37.95
H
REPLACEMENT CHROME BALL FOR
THIS PINTLE
BALL SIZE
PART #
1-7/8"
BY4202 104.55
G
2"
BY4203 104.55
G
2-5/16"
BY4204 112.10
H
Pin w/Chain
BY1100 2.50
H
BALL SIZE
PART #
1-7/8"
BY1780 31.95
H
2"
BY2000 28.90
G
2-5/16"
BY2516 37.95
H
REPLACEMENT CHROME BALL FOR
THIS PINTLE
WITH INSTALLATION INSTRUCTION SHEETS OR TEMPLATES AND
CAPACITY DECALS
BOLT KIT TO MOUNT
NOT INCLUDED
BY8520 6.95
G
PINTLE HOOK MOUNT
These mounts are designed to adapt receiver tubes to multi-height pintle hook applications
Features:
• Continuous welds • Epoxy coating
• Solid shank
• 10,000# capacity
• 2” Shank diameter • 1,000# tongue weight
SHANK
DIMENSIONS
PLATE
DIMENSIONS
PAIR OF
HOLES
M. V. L.
M. G. T. W.
PART #
2" x 9"
5" x 7.38"
4
2,000# 10,000#
BY870 62.60
G
2" x 10.25"
5" x 7.38"
4
2,000# 10,000#
BY107 69.95
B
2" x 12.25"
5" x 12.50”
7
2,000# 10,000#
BY812 94.95
G
2" x 9"
5" x 3.75”
2
4,000# 20,000#
BY840 63.75
G
2" x 10.25"
5" x 5.75”
3
2,800# 14,000#
BY105 66.90
H
