HITCHES
73
2015 TRAILER CATALOG
tires &
wheels
axles, hubs
& springs
tongue
accessories
hitches
electrical
brake
parts
trailer
hardware
locks &
pins
towing &
loading
tie downs
tools
chemicals
TRAILER
RIGID TYPE PINTLE HOOK - 5 TON & 8 TON
INCLUDES MOUNTING INSTRUCTIONS
RIGID TYPE PINTLE HOOK - 20 TON
INCLUDES MOUNTING INSTRUCTIONS
RIGID TYPE PINTLE HOOK - 15 TON
INCLUDES MOUNTING INSTRUCTIONS
M. V. L. = MAXIMUM VERTICAL LOAD M. G. T. W. = MAXIMUM GROSS TOWINGWEIGHT
• Drop forged steel
• Black powder coated finish
• Locking pin included
• Drawbar eye dimensions: 2" to 3" ID with 1-1/4" to 1-5/16"
diameter section
• Boxed
M. V. L.
M. G. T. W.
PART #
5 Ton 2,000# 10,000#
BY4205 54.95
G
8 Ton 3,200# 16,000#
BY4208 59.95
G
• Drop forged steel
• Black powder coated finish
• Locking pin included
• Drawbar eye dimensions: 2" to 3" ID with 1-1/4" to 1-5/8"
diameter section
M. V. L.
M. G. T. W.
PART #
15 Ton 6,000# 30,000#
BY4206 79.95
G
• Drop forged steel
• Black powder coated finish
• Locking pin included
• Drawbar eye dimensions:
2" to 3" ID with 1-1/4" to 1-5/8" diameter section
BOLT KIT TO MOUNT
NOT INCLUDED
BY8525 11.15
L
M. V. L.
M. G. T. W.
PART #
20 Ton 8,000# 40,000#
BY4220 109.95
D
BOLT KIT TO MOUNT
NOT INCLUDED
BY8520 6.95
G
BOLT KIT TO MOUNT
NOT INCLUDED
BY8520 6.95
G
BOLT-ON RECEIVER TUBE - 10 TON
• 2" receiver tube welded to 1/2" thick steel mounting plate with standard 4-Hole pintle hook
pattern
• Cast steel collar
• Solid stress collar opening
• 5/8" hitch pin hole
• Black powder coat finish
DESCRIPTION M. V. L.
M. G. T. W.
PART #
2-1/5" x 6"
2,000#
20,000#
BY4055 66.10
G
