TRAILER
RECEIVER MOUNT -
COMBINATION BALL HITCH - 6 TON
Patented Design
• Single piece, drop forged lower jaw
• Integral shank fits all 2” receiver tubes
• Finished with black powder coat for superior durability and corrosion
resistance
• Eliminates the need for a more costly assembly consisting of a pintle
hook and mounting hardware, plus a significant weight savings
• Individually boxed for storage, shipping and retail display
• Drawbar eye dimensions: 2" to 3" ID with 1-1/4" to 1-5/8" diameter section
• Capacity: 10,000 lbs. M.G.T.W., 2,000# Maximum Vertical Load
Patented Design
WITH INSTALLATION INSTRUCTION SHEETS OR TEMPLATES AND
CAPACITY DECALS
RECEIVER MOUNT -
PINTLE HOOK, 5 TON
DESCRIPTION
PART #
Receiver Mount - Pintle Hook
BY0050 94.95
E
• Single piece, drop forged lower jaw
• Integral shank fits all 2” receiver tubes
• Finished with black powder coat for superior durability and corrosion
resistance
• Eliminates the need for a more costly assembly consisting of a ball hitch,
pintle mount and mounting hardware, plus a significant weight savings
• Individually boxed for storage, shipping and retail display
• Drawbar eye dimensions: 2-1/2" to 3" ID with 1-1/4" to 1-9/16" diameter
section
• Capacity: 12,000 lbs. M.G.T.W., 2,400# Maximum Vertical Load
BALL SIZE
PART #
1-7/8"
BY61780 129.95
E
2"
BY62000 139.95
J
2-5/16"
BY62516 139.95
G
Pin w/Chain
BY1100
2.50
H
BALL SIZE
PART #
1-7/8"
BY1780
31.95
H
2"
BY2000
28.90
G
2-5/16"
BY2516
37.95
H
REPLACEMENT CHROME BALL FOR THIS PINTLE
WITH INSTALLATION INSTRUCTION SHEETS OR TEMPLATES AND
CAPACITY DECALS
TRAILER NOSE PLATE
Features:
• Accepts standard 4-1/2" square bolt pattern
found on most drawbars
• Allows 3 mounting positions
THICKNESS HOLES MEASUREMENTS
PART #
3/4"
8-21/32"
30,000#
BY25750 72.90
G
