AXLES, HUBS & SPRINGS
39
2015 TRAILER CATALOG
tires &
wheels
axles, hubs
& springs
tongue
accessories
hitches
electrical
brake
parts
trailer
hardware
locks &
pins
towing &
loading
tie downs
tools
chemicals
TRAILER
SINGLE AXLE HANGER KIT -
SLIPPER STANDARD DUTY (1-3/4" SPRING)
SINGLE AXLE HANGER KIT -
DOUBLE EYE (SHORT & LONG) - (1-3/4" SPRING)
SINGLE AXLE HANGER KIT -
SLIPPER HEAVY DUTY (2" SPRING)
TANDEM AXLE EQUALIZER KIT -
(SHORT & LONG) - (1-3/4" SPRING)
DETAIL PART #
MFG #
DESCRIPTION
KIT QTY
75-1000
HK1-S100 SINGLE AXLE HANGER
KIT (1-3/4" SPRING)
COMPLETE
18.50
G
1A
75-101
HG-101 Front, rear hanger - 1.44"
4
3.50
G
1B
CS11030B
11030
Bolt - 9/16" - 18 x 3" long
4
2.29
L
1C
CS10864
10864
Nut - 9/16" - 18 NFT
4
0.63
L
DETAIL PART # MFG #
DESCRIPTION
KIT QTY
75-1002
HK1-S201 SINGLE AXLE HANGER KIT
(2" SPRING)
COMPLETE
68.60
H
1A
75-103
HG-103
Front hanger - 4.25"
2
7.40
H
1B
75-105
HG-105
Rear hanger - 5.30"
2
26.05
G
1C
CS11031B
11031
Bolt - 9/16" - 18 x 3-1/2" long
2
2.19
L
1D
75-110
B-100
Bolt - 5/16" - 18 x 3-1/2" long
2
1.15
H
1E
CS10864
10864
Nut - 9/16" - 18 NFT
2
0.63
L
1F
75-112
N-100
Nut - 5/16" - 18 NFT
2
0.20
ZB
DETAIL PART # MFG #
DESCRIPTION
KIT QTY
75-1100
HK1-D100
SINGLE AXLE HANGER KIT
(SHORT)
COMPLETE
20.45
B
75-1101
HK1-D101 SINGLE AXLE HANGER KIT (LONG) COMPLETE
25.25
G
1A
75-101
HG-101
Front hanger for
75-1100
- 1.44"
2
3.50
G
1A
75-102
HG-102
Front hanger for
75-1101
- 3.25"
2
5.70
G
1B
75-100
HG-100
Rear hanger - 1.12"
2
2.05
H
1C
75-120
SHL-102
Shackle link - 3-1/8" hole centers
4
2.10
H
1D
CS11030B
11030
Bolt - 9/16" - 18 x 3" long
6
2.29
L
1E
CS10864
10864
Nut - 9/16" - 18 NFT
6
0.63
L
DETAIL PART # MFG #
DESCRIPTION
KIT QTY
75-1102
EK2-D102 TANDEM AXLE EQUALIZER
KIT (SHORT)
COMPLETE
82.65
G
75-1103
EK2-D103 TANDEM AXLE EQUALIZER
KIT (LONG)
COMPLETE
92.10
H
1A
690990
13-10
Equalizer bar
2
10.40
G
1B
75-101
HG-101 Front, center, rear hanger for
75-2102
- 1.44"
6
3.50
G
1C
75-102
HG-102 Front, center, rear hanger for
75-2103
- 3.25"
6
5.70
G
1D
75-120
SHL-102 Shackle link - 2" hole centers
8
2.10
H
1D
CS11030B
11030
Bolt - 9/16" - 18 x 3" long
14
2.29
L
1E
CS10864
10864
Nut - 9/16" - 18 NFT
14
0.63
L
