AXLES, HUBS & SPRINGS
37
2015 TRAILER CATALOG
tires &
wheels
axles, hubs
& springs
tongue
accessories
hitches
electrical
brake
parts
trailer
hardware
locks &
pins
towing &
loading
tie downs
tools
chemicals
TRAILER
• Heavy 1/4" steel
• Use with 7/16" or 1/2" diameter u-bolts or shackle bolts
• Used on double eye springs
• 1/4" thick plated steel
• Skin packaged (each)
SMITH FRAME STRAPS
GALVANIZED FINISH
PART # MFG # LENGTH HOLE
CENTER
WIDTH BOLT
HOLE SIZE
U/M
CS20016
20016G 4"
2-9/16"
1-1/4"
.565"
EA
1.80
J
CS20017
20017G 5"
3-1/2"
1-1/4"
.565"
EA
1.95
H
CS20018
20018G 4"
2.58"
1"
.565"
EA
1.85
H
CS20028
20028G 6"
4.53"
1-1/4"
.565"
EA
2.52
G
PLAIN FINISH
PART # MFG # LENGTH HOLE
CENTER
WIDTH BOLT
HOLE SIZE
U/M
690962
14100G 4-3/8"
3-1/4"
1-1/4"
9/16"
EA
2.81
AE
TIE DOWN FRAME STRAPS
PART # MFG # LENGTH HOLE
CENTER
WIDTH BOLT
HOLE SIZE
U/M
LR86276
86276
4-3/8"
3-1/4"
1-1/4"
9/16"
EA
6.95
G
TIE DOWN SPRING HANGERS - WELD-ON
2"
A
B
C
• Weld-on
• Sold each
• Front bracket and rear "C" clip bracket
• Use with 1-3/4" spring and 9/16" shackle bolt
Style 1
Style 2
PART # MFG # A B C STYLE LOCATION WEIGHT
LIMIT
PER AXLE
U/M
LR86274
86274 2-1/4" 1-1/2" 1-1/2"
1
FRONT 1000#-3500# EA
4.40
G
LR86275
86275 2"
1"
1"
2
REAR 5200#-8000# EA
3.70
G
• Hot-dipped galvanized brackets bolt beneath trailer frame
• For light duty use with 1-3/4" slipper springs
• Front bracket length of 2-1/4"
• Made of 7 gauge steel
• Uses 9/16" shackle bolt below
SMITH SPRING HANGERS - BOLT ON
PART # MFG # SPRING LOCATION BOLT LENGTH U/M
CS14016
14016G 1-3/4"
FRONT 9/16"
2-1/4"
EA
10.95
G
CS14017
14017G 1-3/4"
REAR 9/16"
2-1/2"
EA
9.85
G
