AXLES, HUBS & SPRINGS
36
tires &
wheels
axles, hubs
& springs
tongue
accessories
hitches
electrical
brake
parts
trailer
hardware
locks &
pins
towing &
loading
tie downs
tools
chemicals
TRAILER
• Each kit contains:
- 4 u-bolts
- 8 lock nuts
- 2 five hole tie plates
• Display packaged
• Zinc plated u-bolts with straps offer extra strength and security when attaching parts or accessories to trailer frame
• Straps are 1-1/4" wide and hot dipped galvanized for protection
• Washers and nuts are also included
• Display packaged
• Zinc, yellow u-bolts
• Fits 1-3/4" wide springs
• Contains parts to attach 2 springs to axle
• Galvanized plates
• Includes: 2 tie plates, 4 u-bolts, 8 locknuts, & washers
• Display packaged
Square
AXLE TIE PLATES
PART # MFG #
A
LONG
LENGTH
B
SHORT
LENGTH
C
BOLT
SPACE
LONG
D
BOLT
SPACE
SHORT
HOLE
DIA.
U/M
230041
TP-R-120 3-1/2"
3-1/2"
2-1/4"
2-1/4"
1/2"
EA
5.90
G
230042
TP-R-220 5-1/2"
3-1/2"
3"
2-1/2"
1/2"
EA
9.95
G
230043
TP-R-320 5-3/4"
3-1/2"
3-1/2"
2-1/4"
1/2"
EA
9.70
G
230044
TP-R-370 5-3/4"
4"
3-1/2"
2-1/2"
1/2"
EA
10.40
G
230050
TP-S-220 3-3/4"
3-3/4"
2-3/4"
2-3/4"
1/2"
EA
7.65
G
TIE DOWN AXLE TIE PLATE KITS
PART # MFG # AXLE
SIZE
AXLE
STYLE
U/M
LR81175
81175 1.90"
ROUND PKG
22.25
G
LR81180
81180 2-3/8" ROUND PKG
26.00
G
LR81185
81185 2"
SQUARE PKG
32.95
G
SMITH AXLE TIE PLATE KITS
PART # MFG # AXLE
SIZE
AXLE
STYLE
U/M
CS23000
23000 1-3/4"
ROUND PKG
26.75
G
CS23002
23002 2-3/8"
ROUND PKG
37.60
G
CS23003
23003
3"
ROUND PKG
33.50
G
CS23102
23102 1-1/2"
SQUARE PKG
18.95
G
CS23103
23103
2"
SQUARE PKG
29.00
G
SMITH U-BOLT WITH FRAME STRAP
PART # MFG # U-BOLT
WIDTH
U-BOLT
LENGTH
STRAP
LENGTH
U/M
CS15903
15903 4-1/8"
3"
6"
PKG
9.05
H
