CYLINDER
WORKS
ATV CYLINDER KITS
continued
Compres-
sioN
Ratio
Cyl.
Dia.
Size
Over
StD.
Displace-
ment
PART #
YAMAHA
CONTINUED
RAPTOR
700
06-14 Standard Bore
HC Cylinder Kit
Standard Bore Hi-comp kit. 11:1 comp, 102mm
Includes: cylinder, piston, rings, top-gaskets. Uses
Vertex #23548
11.1:1 102 0.00
686
880126 639.95
G
GRIZZLY
700
07-14 Standard Bore
Gasket Kit
Standard Bore Top End Gasket Kit Includes (Head,
Base, Exhaust, & Cam chain tensioner)
0
0
880120 85.95
G
GRIZZLY
700
07-13 Standard Bore
Cylinder Kit
Standard Bore kit. 9.2:1 comp, 102mm Includes: cyl-
inder, piston, rings, top-gaskets. Uses Vertex #23623
9.2:1 102 0.00
686
880121 599.95
G
GRIZZLY
700
07-13 Standard Bore
HC Cylinder Kit
Standard Bore Hi-comp kit. 11:1 comp. 102mm
Includes: cylinder, piston, rings, top-gaskets. Uses
Vertex #23548
11.1:1 102 0.00
686
880122 639.95
G
GRIZZLY
700
14 Standard Bore
Cylinder Kit
Standard Bore Kit. 10.1:1 comp. 102mm. Includes
(Cylinder, Piston, Rings, Pin, Clips, Top End Gas-
kets). Uses Vertex #23965.
10.1:1 102
686
880221 749.95
G
GRIZZLY
700
14 Standard Bore
HC Cylinder Kit
Standard Bore Hi-Comp Kit. 11:1 comp. 102mm.
Includes (Cylinder, Piston, Rings, Pin, Clips, Top End
Gaskets). Uses Vertex #23966.
11:1 102
686
880222 749.95
G
YFZ 450 04-09 Big Bore
Gasket Kit
478cc Top End Gasket Kit Includes (Head, Base,
Exhaust, & Cam Chain Tensioner Gaskets)
0
0
880079 85.95
G
YFZ 450R 09-14 Big Bore
Gasket Kit
478cc Top End Gasket Kit Includes (Head, Base,
Exhaust, & Cam Chain Tensioner Gaskets)
0
0
880085 85.95
G
YFZ 450X 10-11 Big Bore
Gasket Kit
478cc Top End Gasket Kit Includes (Head, Base,
Exhaust, & Cam Chain Tensioner Gaskets)
0
0
880085 85.95
G
YFZ 450R 09-14 Big Bore Cylin-
der Kit
(+3mm Big Bore Kit) makes 478cc. Uses Vertex
#23403 Includes (Cylinder, Piston, Rings, Pin, Clips,
Gaskets)
12.5:1 98 3.00
478
880135 649.95
G
YFZ 450X 10-11 Big Bore Cylin-
der Kit
(+3mm Big Bore Kit) makes 478cc. Uses Vertex
#23403 Includes (Cylinder, Piston, Rings, Pin, Clips,
Gaskets)
12.5:1 98 3.00
478
880135 649.95
G
RAPTOR
700
06-14 Big Bore
Gasket Kit
Top End Gasket Kit Includes (Head, Base, Exhaust,
& Cam chain tensioner)
0
0
880127 85.95
G
RAPTOR
700
06-14 Big Bore Cylin-
der Kit
(+3mm Big Bore Kit) makes 727cc. 9.2:1 comp. Uses
Vertex #23626.
9.2:1 105 3.00
727
880128 799.95
G
GRIZZLY
700
07-14 Big Bore
Gasket Kit
727cc Top End Gasket Kit. Includes (Head, Base,
Exhaust & Cam Chain Tensioner)
0
0
880123 85.95
G
GRIZZLY
700
07-13 Big Bore Cylin-
der Kit
(+3mm Big Bore Kit) 727cc. 9.2:1 comp. Includes
(Cylinder, Piston, Pin, Rings, Clips, Top End Gaskets)
Uses Vertex #23626. When used with Hot Rods
#4179 makes 770cc.
9.2:1 105 3.00
727
880124 799.95
G
GRIZZLY
700
14 Big Bore Cylin-
der Kit
(+3mm Big Bore Kit) 727cc. 9.2:1 comp. Includes
(Cylinder, Piston, Pin, Rings, Clips, Top End Gaskets)
Uses Vertex #23967. When used with Hot Rods
#4179 makes 770cc.
10.1:1 105 3.00
727
880223 799.95
G
YFZ 450 04-12 Big Bore
Gasket Kit
468cc Top End Gasket Kit Includes (Head, Base,
Exhaust, & Cam Chain Tensioner Gaskets)
0
0
880089 85.95
G
YFZ 450 04-13 Big Bore
Gasket Kit
478cc Top End Gasket Kit Includes (Head, Base,
Exhaust, & Cam Chain Tensioner Gaskets)
0
0
880154 85.95
G
YFZ 450 04-13 Big Bore Cylin-
der Kit
(+3mm Big Bore Kit) Makes 468cc in 04-05 models.
Makes 478cc in 06-12 models. Std compression.
Uses Vertex #23403. Includes (Cylinder, Piston,
Rings, Pin, Clips, Gaskets)
12.0:1 98 3.00
478
880155 649.95
G
