VERTEX PISTONS
Type
Version Year Description
Comp.
Ratio
Cyl
Bore
(mm)
Piston
Diam.
(mm)
Disp
Size
Over
STD
Top End
Piston
Kit
Part #
Piston
Kit
Part #
Repl
Ring(s)
Part #
Wrist
Pin
Part #
Circlip
Part #
YAMAHA
CONTINUED
RAPTOR 700 FORGED
HIGH COMP
06-13 Top end piston kit includes: piston, rings, pins,
circlips, top end gaskets, and cam chain
11:1 102 101.97 700
903163
RAPTOR 700 FORGED
HIGH COMP
06-13 Top end piston kit includes: piston, rings, pins,
circlips, top end gaskets, and cam chain
11:1 102 101.96 700
903164
RAPTOR 700 FORGED
HIGH COMP
06-13 Top end piston kit includes: piston, rings, pins,
circlips, top end gaskets, and cam chain
11:1 102 101.95 700
903165
RAPTOR 700
CAST
REPLICA
06-13 Top end piston kit includes: piston, rings, pins,
circlips, top end gaskets, and wrist pin bearing
when applicable.
9.2:1 102 101.97 700
901764
RAPTOR 700
CAST
REPLICA
06-13 Top end piston kit includes: piston, rings, pins,
circlips, top end gaskets, and wrist pin bearing
when applicable.
9.2:1 102 101.96 700
901763
RAPTOR 700
CAST
REPLICA
06-13 Top end piston kit includes: piston, rings, pins,
circlips, top end gaskets, and wrist pin bearing
when applicable.
9.2:1 102 101.95 700
901762
RAPTOR 700 FORGED
HIGH COMP
06-13 Top end piston kit includes: piston, rings, pins,
circlips, top end gaskets, and wrist pin bearing
when applicable.
11:1 102 101.97 700
901761
RAPTOR 700 FORGED
HIGH COMP
06-13 Top end piston kit includes: piston, rings, pins,
circlips, top end gaskets, and wrist pin bearing
when applicable.
11:1 102 101.96 700
901760
RAPTOR 700 FORGED
HIGH COMP
06-13 Top end piston kit includes: piston, rings, pins,
circlips, top end gaskets, and wrist pin bearing
when applicable.
11:1 102 101.95 700
901759
RAPTOR 700 FORGED
HIGH COMP
06-13 High Compression Piston kit; 11.0:1. Kit includes:
Piston, rings, pin, clips
11:1 102 101.95 700
901463 901133 901048 901688
RAPTOR 700 FORGED
HIGH COMP
06-13 High Compression Piston kit; 11.0:1. Kit includes:
Piston, rings, pin, clips
11:1 102 101.96 700
901464 901133 901048 901688
RAPTOR 700 FORGED
HIGH COMP
06-13 High Compression Piston kit; 11.0:1. Kit includes:
Piston, rings, pin, clips
11:1 102 101.97 700
901465 901133 901048 901688
RAPTOR 700
CAST
REPLICA
06-13 Replica Piston kit; Kit includes: Piston, rings, pin,
clips
9.2:1 102 101.95 700
901527 901133 901048 901688
RAPTOR 700
CAST
REPLICA
06-13 Replica Piston kit; Kit includes: Piston, rings, pin,
clips
9.2:1 102 101.96 700
901528 901133 901048 901688
RAPTOR 700
CAST
REPLICA
06-13 Replica Piston kit; Kit includes: Piston, rings, pin,
clips
9.2:1 102 101.97 700
901529 901133 901048 901688
RAPTOR 700 FORGED BIG
BORE
06-13 Big Bore Piston kit; +3mm makes 727cc. Kit
includes: Piston, rings, pin, clips
9.2:1 105 104.95 727
3
901531 901134 901048 901688
RAPTOR 700 FORGED BIG
BORE
06-13 Big Bore Piston kit; +3mm makes 727cc. Kit
includes: Piston, rings, pin, clips
9.2:1 105 104.96 727
3
901532 901134 901048 901688
RAPTOR 700 FORGED BIG
BORE
06-13 Big Bore Piston kit; +3mm makes 727cc. Kit
includes: Piston, rings, pin, clips
9.2:1 105 104.97 727
3
901533 901134 901048 901688
WARRIOR
350
CAST
REPLICA
87-04 Replica Piston kit; Kit includes: Piston, rings, pin,
clips
10.25:1 83 82.95 350
901003 901630 901026 901684
WARRIOR
350
CAST
REPLICA
87-04 Replica Piston kit; +0.50mm makes 353cc. Kit
includes: Piston, rings, pin, clips
10.25:1 83.5 83.45 353 0.5
901073 901631 901026 901684
WARRIOR
350
CAST
REPLICA
87-04 Replica Piston kit; +1.00mm makes 357cc. Kit
includes: Piston, rings, pin, clips
10.25:1 84 83.95 357
1
901074 901632 901026 901684
WARRIOR
350
CAST
STROKER
87-04 Stroker Performance piston kit; +1mm makes 381cc.
Must be used with Hot Rods stroker crankshaft
4143. Kit includes: Piston, rings, pin, clips
9.2:1 84 83.94 381
1
901523 901632 901026 901684
YFZ 450
FORGED
HIGH COMP
04-13 Top end piston kit includes: piston, rings, pins,
circlips, top end gaskets, and cam chain
13:1 95 94.97 450
903167
YFZ 450
FORGED
HIGH COMP
04-13 Top end piston kit includes: piston, rings, pins,
circlips, top end gaskets, and cam chain
13:1 95 94.96 450
903168
YFZ 450
FORGED
HIGH COMP
04-13 Top end piston kit includes: piston, rings, pins,
circlips, top end gaskets, and cam chain
13:1 95 94.95 450
903169
YFZ 450
FORGED
REPLICA
04-13 Top end piston kit includes: piston, rings, pins,
circlips, top end gaskets, and cam chain
12:1 95 94.97 450
903170
YFZ 450
FORGED
REPLICA
04-13 Top end piston kit includes: piston, rings, pins,
circlips, top end gaskets, and cam chain
12:1 95 94.96 450
903171
YFZ 450
FORGED
REPLICA
04-13 Top end piston kit includes: piston, rings, pins,
circlips, top end gaskets, and cam chain.
12:1 95 94.95 450
903172
