CYLINDER
WORKS
ATV CYLINDER KITS
continued
Compres-
sioN
Ratio
Cyl.
Dia.
Size
Over
StD.
Displace-
ment
PART #
HONDA
CONTINUED
TRX 450ER 06-14 Standard Bore
Gasket Kit
Standard bore top end gasket kit. Includes (Head,
Base, Exhaust, & Cam Chain Tensioner Gaskets)
0
0
880099 85.95
G
TRX 450R 06-09 Standard Bore
Cylinder Kit
Standard Bore kit. 12.0:1 comp, 96mm Includes: cyl-
inder, piston, rings, top-gaskets. Uses Vertex #23522
12.0:1 449
0
449
880100 569.95
G
TRX 450ER 06-14 Standard Bore
Cylinder Kit
Standard Bore kit. 12.0:1 comp, 96mm Includes: cyl-
inder, piston, rings, top-gaskets. Uses Vertex #23522
12.0:1 449
0
449
880100 569.95
G
TRX 450R 06-09 Standard Bore
HC Cylinder Kit
Standard Bore Hi-comp kit. 13.5:1, 96mm Includes:
cylinder, piston, rings, and top-end gaskets. Uses
Vertex# 23549
13.5:1 96
0
449
880101 599.95
G
TRX 450ER 06-14 Standard Bore
HC Cylinder Kit
Standard Bore Hi-comp kit. 13.5:1, 96mm Includes:
cylinder, piston, rings, and top-end gaskets. Uses
Vertex# 23549
13.5:1 96
0
449
880101 599.95
G
TRX 700XX 08-09 Standard Bore
Gasket Kit
Standard bore top end gasket kit. Includes (Head,
Base, Exhaust, & Cam Chain Tensioner Gaskets)
0
0
880109 85.95
G
TRX 700XX 08-09 Standard Bore
Cylinder Kit
Standard Bore kit. 10:1 comp, 102mm Includes: cyl-
inder, piston, rings, top-gaskets. Uses Vertex #23638
10:1 102
0
686
880110 699.95
G
TRX 700XX 08-09 Standard Bore
HC Cylinder Kit
Standard Bore Hi-comp kit. 102mm Includes: cylin-
der, piston, rings, top-gaskets. Uses Vertex #23639
10.9:1 102
0
686
880111 699.95
G
TRX 450R 04-05 Big Bore
Gasket Kit
479cc Top End Gasket Kit Includes (Head, Base,
Exhaust, & Cam Chain Tensioner Gaskets)
0
0
880107 85.95
G
TRX 450R 04-05 Big Bore Cylin-
der Kit
(+3mm Big Bore Kit) makes 479cc. 10.5:1 comp.
Uses Vertex #23531. When using Hot Rods #4160
makes 500cc. Includes (Cylinder, Piston, Rings, Pin,
Clips, Gaskets)
10.5:1 97 3.00
479
880108 649.95
G
TRX 450R 06-09 Big Bore
Gasket Kit
487cc Top End Gasket Kit Includes (Head, Base,
Exhaust, & Cam Chain Tensioner Gaskets)
0
0
880102 85.95
G
TRX 450ER 06-14 Big Bore
Gasket Kit
487cc Top End Gasket Kit Includes (Head, Base,
Exhaust, & Cam Chain Tensioner Gaskets)
0
0
880102 85.95
G
TRX 450R 06-09 Big Bore Cylin-
der Kit
(+3mm Big Bore Kit) makes 477cc. 12.0:1 compres-
sion. Uses Vertex #23523. When using Hot Rods
4170 makes 500cc. Includes (Cylinder, Piston, Rings,
Pin, Clips, Gaskets)
12.0:1 99 3.00
477
880103 649.95
G
TRX 450ER 06-14 Big Bore Cylin-
der Kit
(+3mm Big Bore Kit) makes 477cc. 12.0:1 compres-
sion. Uses Vertex #23523. When using Hot Rods
4170 makes 500cc Includes (Cylinder, Piston, Rings,
Pin, Clips, Gaskets)
12.0:1 99 3.00
477
880103 649.95
G
TRX 700XX 08-09 Big Bore
Gasket Kit
727cc Top End gasket kit
0
0
880112 85.95
G
TRX 700XX 08-09 Big Bore Cylin-
der Kit
(+3mm Big Bore Kit) makes 727cc. std compression.
Uses Vertex #23640.
10:1 105 3.00
727
880113 749.95
G
KAWASAKI
BRUTE
FORCE 750
05-15 Cylinder Standard Bore 85mm; front cylinder only
8.8:1 85
0
749
880206 299.95
G
BRUTE
FORCE 750
05-15 Cylinder Standard Bore 85mm; rear cylinder only
8.8:1 85
0
749
880207 299.95
G
KFX 400
03-06 Cylinder Standard Bore 90mm
11.3:1 90
0
398
880158 269.95
G
BRUTE
FORCE 750
05-15 Standard Bore
Gasket Kit
Standard Bore Top-End Gasket Kit (Head, Base, &
Exhaust Gaskets), Front Cylinder Only
0
0
880210 89.95
G
BRUTE
FORCE 750
05-14 Standard Bore
Cylinder Kit
Standard Bore Cylinder Kit, 85mm; 8.8:1 comp. Uses
Vertex# 23908. Front cylinder kit only
8.8:1 85
749
880208 569.95
G
BRUTE
FORCE 750
05-14 Standard Bore
HC Cylinder Kit
Standard Bore Hi Comp cylinder kit, 85mm, 11.5:1.
Uses Vertex# 23909. Front cylinder kit only
11.5:1 85
749
880212 599.95
G
BRUTE
FORCE 750
15 Standard Bore
Cylinder Kit
Standard Bore Cylinder Kit. Includes: Cylinder, Piston
Kit and Top-End Gasket Kit. *Front Cylinder Only.
Uses Vertex # 24024.
9.3:1 85
749
880224 569.95
G
BRUTE
FORCE 750
15 Standard Bore
HC Cylinder Kit
Standard Bore Hi-Comp Cylinder Kit. Includes:
Cylinder, Piston Kit and Top-End Gasket Kit. *Front
Cylinder Only. Uses Vertex # 24025.
85
749
880225 599.95
G
BRUTE
FORCE 750
05-15 Standard Bore
Gasket Kit
Standard Bore Top-End Gasket Kit (Head, Base, &
Exhaust Gaskets), Rear Cylinder Only
0
0
880211 89.95
G
BRUTE
FORCE 750
05-14 Standard Bore
Cylinder Kit
Standard Bore cylinder kit, 85mm; 8.8:1 comp. Uses
Vertex# 23908. Rear cylinder kit only
8.8:1 85
749
880209 569.95
G
