CYLINDER
WORKS
ATV CYLINDER KITS
continued
Compres-
sioN
Ratio
Cyl.
Dia.
Size
Over
StD.
Displace-
ment
PART #
SUZUKI
LTZ 400
03-14 Cylinder Standard Bore 90mm
11.3:1 90
0
398
880158 269.95
G
LT-R 450 06-09 Cylinder Standard Bore 95.5mm
11.7:1 95.5 0
449
880216 279.95
G
LTZ 400
03-14 Standard Bore
Gasket Kit
Standard bore top end gasket kit. Includes (Head,
Base, Exhaust, & Cam Chain Tensioner Gaskets)
0
0
880034 85.95
G
LTZ 400
03-14 Standard Bore
Cylinder Kit
Standard Bore kit. 11.3:1 comp, 90mm Includes: cyl-
inder, piston, rings, top-gaskets. Uses Vertex #22951
11.3:1 90 0.00
398
880035 559.95
G
LTZ 400
03-14 Standard Bore
HC Cylinder Kit
Standard Bore Hi-comp kit. 13.5:1 comp, 90mm
Includes: cylinder, piston, rings, top-gaskets. Uses
Vertex #23550
13.5:1 90 0.00
398
880036 579.95
G
LT-R 450 06-09 Standard Bore
Gasket Kit
Standard bore top end gasket kit. Includes (Head,
Base, Exhaust, & Cam Chain Tensioner Gaskets)
0
0
880114 85.95
G
LT-R 450 06-09 Standard Bore
Cylinder Kit
Standard Bore kit. 11.7:1 comp, 95.5mm Includes:
cylinder, piston, rings, top-gaskets. Uses Vertex
#23532
11.7:1 95.5 0.00
449
880115 559.95
G
LT-R 450 06-09 Standard Bore
HC Cylinder Kit
Standard Bore Hi-comp kit. 13.0:1 comp, 98mm
Includes: cylinder, piston, rings, top-gaskets. Uses
Vertex #23553
13.0:1 95.5 0.00
449
880116 579.95
G
LTZ 400
03-14 Big Bore
Gasket Kit
434cc Top End Gasket Kit Includes (Head, Base,
Exhaust, & Cam Chain Tensioner Gaskets)
0
0
880037 85.95
G
LTZ 400
03-14 Big Bore Cylin-
der Kit
(+4mm Big Bore Kit) 434cc. Std compression. Uses
Vertex #23533. When using Hot Rods #4259 makes
469cc. Includes (Cylinder, Piston, Rings, Pin, Clips,
Gaskets)
11.3:1 94 4.00
434
880038 649.95
G
LT-R 450 06-09 Big Bore
Gasket Kit
474cc Top End Gasket Kit Includes (Head, Base,
Exhaust, & Cam Chain Tensioner Gaskets)
0
0
880117 85.95
G
LT-R 450 06-09 Big Bore Cylin-
der Kit
(+2.5mm Big Bore Kit) 474cc. Std compression. Uses
Vertex #23521. When using Hot Rods #4176 makes
496cc. Includes (Cylinder, Piston, Rings, Pin, Clips,
Gaskets)
11.7:1 98 2.50
474
880118 649.95
G
YAMAHA
YFZ 450 04-13 Cylinder Standard Bore 95mm
12.0:1 95
0
449
880159 249.95
G
YFZ 450R 09-14 Cylinder Standard Bore 95mm
12.5:1 95
0
449
880199 269.95
G
YFZ 450X 10-11 Cylinder Standard Bore 95mm
12.5:1 95
0
449
880199 269.95
G
RAPTOR
700
06-14 Cylinder Standard Bore 102mm
9.2:1 102
0
686
880217 349.95
G
GRIZZLY
700
07-14 Cylinder Standard Bore 102mm
9.2:1 102
0
686
880218 349.95
G
YFZ 450 04-13 Standard Bore
Gasket Kit
Standard Bore Top End Gasket Kit Includes (Head,
Base, Exhaust, & Cam chain tensioner)
0
0
880076 85.95
G
YFZ 450 04-13 Standard Bore
Cylinder Kit
Standard Bore kit. 12.0:1 comp, 95mm Includes: cyl-
inder, piston, rings, top-gaskets. Uses Vertex #22984
12.0:1 95 0.00
449
880129 559.95
G
YFZ 450 04-13 Standard Bore
HC Cylinder Kit
Standard Bore Hi-comp kit. 13.0:1 comp, 95mm
Includes: cylinder, piston, rings, top-gaskets. Uses
Vertex #23551
13.0:1 95 0.00
449
880130 579.95
G
YFZ 450R 09-14 Standard Bore
Gasket Kit
Standard Bore Top End Gasket Kit Includes (Head,
Base, Exhaust, & Cam chain tensioner)
0
0
880082 85.95
G
YFZ 450X 10-11 Standard Bore
Gasket Kit
Standard Bore Top End Gasket Kit Includes (Head,
Base, Exhaust, & Cam chain tensioner)
0
0
880082 85.95
G
YFZ 450R 09-14 Standard Bore
Cylinder Kit
Standard Bore kit. 12.0:1 comp, 95mm Includes: cyl-
inder, piston, rings, top-gaskets. Uses Vertex #22984
12.5:1 95 0.00
449
880133 559.95
G
YFZ 450X 10-11 Standard Bore
Cylinder Kit
Standard Bore kit. 12.0:1 comp, 95mm Includes: cyl-
inder, piston, rings, top-gaskets. Uses Vertex #22984
12.5:1 95 0.00
449
880133 559.95
G
YFZ 450R 09-14 Standard Bore
HC Cylinder Kit
Standard Bore Hi-comp kit. 13.0:1 comp, 95mm
Includes: cylinder, piston, rings, top-gaskets. Uses
Vertex #23551
13.5:1 95 0.00
449
880134 579.95
G
YFZ 450X 10-11 Standard Bore
HC Cylinder Kit
Standard Bore Hi-comp kit. 13.0:1 comp, 95mm
Includes: cylinder, piston, rings, top-gaskets. Uses
Vertex #23551
13.5:1 95 0.00
449
880134 579.95
G
RAPTOR
700
06-14 Standard Bore
Gasket Kit
Standard Bore Top End Gasket Kit Includes (Head,
Base, Exhaust, & Cam chain tensioner)
0
0
880119 85.95
G
RAPTOR
700
06-14 Standard Bore
Cylinder Kit
Standard Bore kit. 9.2:1 comp, 102mm Includes: cyl-
inder, piston, rings, top-gaskets. Uses Vertex #23623
9.2:1 102 0.00
686
880125 599.95
G
