As an alternative to costly OEM cylinders or the time consuming process of re-plating existing
cylinders, Cylinder Works offers enthusiasts access to a complete line of OEM quality dirt
bike and ATV replacement cylinders and cylinder kits. In addition to standard bore, stock
compression replacement cylinder kits, Cylinder Works also turns up the horsepower with
a full line of high-compression and big bore cylinder kits that look just like stock. Each kit
comes complete with piston, rings and gaskets to get back on the trail quickly.
Cylinder Works OEM Replacement Cylinders and Cylinder Kits (standard bore/stock compression)
Re-plating or repairing an OEM cylinder takes time, And replacing an OEM cylinder with another OEM cyl-
inder takes money - plenty of it. But Cylinder Works has a better answer: Get new now, get Cylinder Works!
Each Cylinder Works replacement cylinder is:
Stock in appearance • Precision hones • Nickel silicon carbide plated • OEM quality without the OEM
price.
Cylinder Works replacement cylinder kits also contain:
Gaskets and seals needed for installation • Hand fitted, premium
quality Vertex piston kit complete with piston rings, wrist pin and cir-
clips.
Cylinder Works High-Compression Kits (standard bore/high compression)
As we all know, higher compression equals more horsepower and that’s exactly what Cylinder Works high
compression cylinder kits provide. Just like out OEM replacement cylinders, our high compression cylinder
kits look like stock, but they’re not. In addition to their stock appearance, Cylinder Works high compression
cylinder kits also feature precision honing, nickel silicon carbide plating and a price that’s hard to beat.
With the exception of a mechanic, the Cylinder Works big bore kits provide everything you
need to transform a bike or ATV from modest to monster in one box.
In addition to the stock appearance, nickel silicon carbide plated, precision honed, big bore
cylinder, each kit contains:
All needed gaskets and seals to complete the installation • A Vertex big bore piston, com-
plete with piston rings, wrist pin and circlips.
CYLINDER
WORKS
CYLINDER KITS
Compres-
sioN
Ratio
Cyl.
Dia.
Size
Over
StD.
Displace-
ment
PART #
ARCTIC CAT
DVX 400 04-08 Cylinder Standard Bore 90mm
11.3:1 90
0
398
880158 269.95
G
DVX 400 04-08 Standard Bore
Gasket Kit
Standard bore top end gasket kit. Includes (Head,
Base, Exhaust, & Cam Chain Tensioner Gaskets)
0
0
880034 85.95
G
DVX 400 04-08 Standard Bore
Cylinder Kit
Standard Bore kit. 11.3:1 comp, 90mm Includes: cyl-
inder, piston, rings, top-gaskets. Uses Vertex #22951
11.3:1 90 0.00
398
880035 559.95
G
DVX 400 04-08 Standard Bore
HC Cylinder Kit
Standard Bore Hi-comp kit. 13.5:1 comp, 90mm
Includes: cylinder, piston, rings, top-gaskets. Uses
Vertex #23550
13.5:1 90 0.00
398
880036 579.95
G
DVX 400 04-08 Big Bore
Gasket Kit
434cc Top End Gasket Kit Includes (Head, Base,
Exhaust, & Cam Chain Tensioner Gaskets)
0
0
880037 85.95
G
DVX 400 04-08 Big Bore Cylin-
der Kit
(+4mm Big Bore Kit) 434cc. Std compression. Uses
Vertex #23533. When using Hot Rods #4259 makes
469cc. Includes (Cylinder, Piston, Rings, Pin, Clips,
Gaskets)
11.3:1 94 4.00
4344
880038 649.95
G
HONDA
TRX 450R 04-05 Cylinder Standard Bore 94mm
10.5:1 94
0
449
880201 289.95
G
TRX 450R 06-09 Cylinder Standard Bore 96mm
12.0:1 96
0
449
880202 269.95
G
TRX 450ER 06-14 Cylinder Standard Bore 96mm
12.0:1 96
0
449
880202 269.95
G
TRX 700XX 08-09 Cylinder Standard Bore 102mm
10:1 102
0
686
880203 349.95
G
TRX 450R 04-05 Standard Bore
Gasket Kit
Standard Bore Top-End Gasket Kit. Includes (Head,
Base, Exhaust, & Cam Chain Tensioner Gaskets).
0
0
880104 85.95
G
TRX 450R 04-05 Standard Bore
Cylinder Kit
Standard Bore Kit. 10.5:1 comp, 94mm. Includes
(Cylinder, Piston, Rings, Top-End Gaskets). Uses
Vertex #23163.
10.5:1 94
0
449
880105 559.95
G
TRX 450R 04-05 Standard Bore
HC Cylinder Kit
Standard Bore Hi-Comp Kit. 13.1:1 comp, 94mm.
Includes (Cylinder, Piston, Rings, Top-End Gaskets).
Uses Vertex #23546.
13.1:1 94
0
94
880106 599.95
G
TRX 450R 06-09 Standard Bore
Gasket Kit
Standard bore top end gasket kit. Includes (Head,
Base, Exhaust, & Cam Chain Tensioner Gaskets)
0
0
880099 85.95
G
