VERTEX PISTONS
Type
Version Year Description
Comp.
Ratio
Cyl
Bore
(mm)
Piston
Diam.
(mm)
Disp
Size
Over
STD
Top End
Piston
Kit
Part #
Piston
Kit
Part #
Repl
Ring(s)
Part #
Wrist
Pin
Part #
Circlip
Part #
YAMAHA
CONTINUED
BLASTER
200
CAST
REPLICA
88-06 Replica Piston kit; +2.00mm. Kit includes: Piston,
rings, pin, clip
STD
68 67.95 207
2
901065 901756 901027 901675
GRIZZLY 660
CAST
REPLICA
02-08 Top end piston kit includes: piston, rings, pins,
circlips, top end gaskets, and cam chain
9.1:1 100 99.95 660 STD
903159
GRIZZLY 660
CAST
REPLICA
02-08 Top end piston kit includes: piston, rings, pins,
circlips, top end gaskets, and wrist pin bearing
when applicable.
9.1:1 100 99.95 660 STD
901758
GRIZZLY 660
CAST
REPLICA
02-08 Replica Piston kit; Kit includes: Piston, rings, pin,
clips
9.1:1 100 99.95 660
901004 901624 901028 901679
GRIZZLY 660
CAST
REPLICA
02-08 Replica Piston kit; +0.50mm makes 666cc. Kit
includes: Piston, rings, pin, clips
9.1:1 100.5 100.45 666 0.5
901075 901625 901028 901679
GRIZZLY 660
CAST
REPLICA
02-08 Replica Piston kit; +1.00mm makes 673cc. Kit
includes: Piston, rings, pin, clips
9.1:1 101 100.95 673
1
901076 901626 901028 901679
GRIZZLY 660 FORGED
HIGH COMP
02-08 High Compression Piston kit; 11.0:1. Kit includes:
Piston, rings, pin, clips
11:1 100 99.95 660
901479 901624 901029 901679
GRIZZLY 660 FORGED
HIGH COMP
02-08 High Compression Piston kit; 11.0:1. Kit includes:
Piston, rings, pin, clips
11:1 100 99.96 660
901480 901624 901029 901679
GRIZZLY 660 FORGED
HIGH COMP
02-08 High Compression Piston kit; 11.0:1. Kit includes:
Piston, rings, pin, clips
11:1 100 99.97 660
901481 901624 901029 901679
GRIZZLY 700 FORGED
REPLICA
14 Forged Replica Piston kit; 10.1:1 comp. Kit includes:
Piston, rings, pin, clips
10.1:1 102 101.95 700
903185 901133 903201 901688
GRIZZLY 700 FORGED
REPLICA
14 Forged Replica Piston kit; 10.1:1 comp. Kit includes:
Piston, rings, pin, clips
10.1:1 102 101.96 700
903186 901133 903201 901688
GRIZZLY 700 FORGED
REPLICA
14 Forged Replica Piston kit; 10.1:1 comp. Kit includes:
Piston, rings, pin, clips
10.1:1 102 101.97 700
903187 901133 903201 901688
GRIZZLY 700 FORGED
HIGH COMP
14 Forged High Comp Piston kit; 11.1:1 comp. Kit
includes: Piston, rings, pin, clips
11.1:1 102 101.95 700
903188 901133 903201 901688
GRIZZLY 700 FORGED
HIGH COMP
14 Forged High Comp Piston kit; 11.1:1 comp. Kit
includes: Piston, rings, pin, clips
11.1:1 102 101.96 700
903189 901133 903201 901688
GRIZZLY 700 FORGED
HIGH COMP
14 Forged High Comp Piston kit; 11.1:1 comp. Kit
includes: Piston, rings, pin, clips
11.1:1 102 101.97 700
903190 901133 903201 901688
GRIZZLY 700 FORGED BIG
BORE
14 Forged Big Bore Piston kit; 10.1:1 comp. Makes
727cc. Kit includes: Piston, rings, pin, clips
10.1:1 105 104.95 727
3
903191 901134 903201 901688
GRIZZLY 700 FORGED BIG
BORE
14 Forged Big Bore Piston kit; 10.1:1 comp. Makes
727cc. Kit includes: Piston, rings, pin, clips
10.1:1 105 104.96 727
3
903192 901134 903201 901688
GRIZZLY 700 FORGED BIG
BORE
14 Forged Big Bore Piston kit; 10.1:1 comp. Makes
727cc. Kit includes: Piston, rings, pin, clips
10.1:1 105 104.97 727
3
903193 901134 903201 901688
GRIZZLY 700
CAST
REPLICA
07-13 Top end piston kit includes: piston, rings, pins,
circlips, top end gaskets, and cam chain
9.2:1 102 101.97 700
903160
GRIZZLY 700
CAST
REPLICA
07-13 Top end piston kit includes: piston, rings, pins,
circlips, top end gaskets, and cam chain
9.2:1 102 101.96 700
903161
GRIZZLY 700
CAST
REPLICA
07-13 Top end piston kit includes: piston, rings, pins,
circlips, top end gaskets, and cam chain
9.2:1 102 101.95 700
903162
GRIZZLY 700 FORGED
HIGH COMP
07-13 Top end piston kit includes: piston, rings, pins,
circlips, top end gaskets, and cam chain
11:1 102 101.97 700
903163
GRIZZLY 700 FORGED
HIGH COMP
07-13 Top end piston kit includes: piston, rings, pins,
circlips, top end gaskets, and cam chain
11:1 102 101.96 700
903164
GRIZZLY 700 FORGED
HIGH COMP
07-13 Top end piston kit includes: piston, rings, pins,
circlips, top end gaskets, and cam chain
11:1 102 101.95 700
903165
GRIZZLY 700
CAST
REPLICA
07-13 Top end piston kit includes: piston, rings, pins,
circlips, top end gaskets, and wrist pin bearing
when applicable.
9.2:1 102 101.97 700
901764
GRIZZLY 700
CAST
REPLICA
07-13 Top end piston kit includes: piston, rings, pins,
circlips, top end gaskets, and wrist pin bearing
when applicable.
9.2:1 102 101.96 700
901763
GRIZZLY 700
CAST
REPLICA
07-13 Top end piston kit includes: piston, rings, pins,
circlips, top end gaskets, and wrist pin bearing
when applicable.
9.2:1 102 101.95 700
901762
GRIZZLY 700 FORGED
HIGH COMP
07-13 Top end piston kit includes: piston, rings, pins,
circlips, top end gaskets, and wrist pin bearing
when applicable.
11:1 102 101.97 700
901761
