CYLINDER
WORKS
ATV CYLINDER KITS
continued
Compres-
sioN
Ratio
Cyl.
Dia.
Size
Over
StD.
Displace-
ment
PART #
kawasaki
CONTINUED
BRUTE
FORCE 750
05-14 Standard Bore
HC Cylinder Kit
Standard Bore Hi Comp cylinder kit, 85mm, 11.5:1.
Uses Vertex# 23909. Rear cylinder kit only
11.5:1 85
749
880213 599.95
G
BRUTE
FORCE 750
15 Standard Bore
Cylinder Kit
Standard Bore Cylinder Kit. Includes: Cylinder, Piston
Kit and Top-End Gasket Kit. *Rear Cylinder Only.
Uses Vertex # 24024.
9.3:1 85
749
880226 569.95
G
BRUTE
FORCE 750
15 Standard Bore
HC Cylinder Kit
Standard Bore Hi-Comp Cylinder Kit. Includes:
Cylinder, Piston Kit and Top-End Gasket Kit. *Rear
Cylinder Only. Uses Vertex # 24025.
85
749
880227 599.95
G
BRUTE
FORCE 750
05-15 Big Bore
Gasket Kit
860cc Top End Gasket Kit. Includes (2 Base, 2 Head,
Exhaust, & Chain Tensioner Gaskets)
0
0
880205 179.95
G
BRUTE
FORCE 750
05-14 Big Bore Cylin-
der Kit
+6mm Big Bore Kit, 9:1 comp, 91mm, makes 860cc.
Uses Vertex# 23910. Includes front and rear cylin-
ders, pistons kits, and top end gaskets. *Requires
case machining on certain years.
9.0:1 91 6.00
860
880204 1295.95
G
BRUTE
FORCE 750
15 Big Bore Cylin-
der Kit
+6mm Big Bore Cylinder Kit. Includes: Front & Rear
Cylinders, Piston Kits and Top-End Gasket Kits. Uses
Vertex # 24026.
10.5:1 91 6.00
859
880228 1295.95
G
KFX 400 03-06 Standard Bore
Gasket Kit
Standard bore top end gasket kit. Includes (Head,
Base, Exhaust, & Cam Chain Tensioner Gaskets)
0
0
880034 85.95
G
KFX 400 03-06 Standard Bore
Cylinder Kit
Standard Bore kit. 11.3:1 comp, 90mm Includes: cyl-
inder, piston, rings, top-gaskets. Uses Vertex #22951
11.3:1 90 0.00
398
880035 559.95
G
KFX 400 03-06 Standard Bore
HC Cylinder Kit
Standard Bore Hi-comp kit. 13.5:1 comp, 90mm
Includes: cylinder, piston, rings, top-gaskets. Uses
Vertex #23550
13.5:1 90 0.00
398
880036 579.95
G
KFX 400 03-06 Big Bore
Gasket Kit
434cc Top End Gasket Kit Includes (Head, Base,
Exhaust, & Cam Chain Tensioner Gaskets)
0
0
880037 85.95
G
KFX 400 03-06 Big Bore Cylin-
der Kit
(+4mm Big Bore Kit) 434cc. Std compression. Uses
Vertex #23533. When using Hot Rods #4259 makes
469cc. Includes (Cylinder, Piston, Rings, Pin, Clips,
Gaskets)
11.3:1 94 4.00
434
880038 649.95
G
POLARIS
SPORTS-
MAN 700
04-08 Cylinder Standard Bore 80mm
10.2:1 80
0
769
880220 429.95
G
SPORTS-
MAN 800
05-14 Cylinder Standard Bore 80mm
10.2:1 80
0
769
880220 429.95
G
SPORTS-
MAN 700
04-08 Standard Bore
Gasket Kit
769cc Top End Gasket Kit. Includes: head, base, cam
chain tensioner, and exhaust gaskets.
0
0
880229 149.95
G
SPORTS-
MAN 800
05-10 Standard Bore
Gasket Kit
769cc Top End Gasket Kit. Includes: head, base, cam
chain tensioner, and exhaust gaskets.
0
0
880229 149.95
G
SPORTS-
MAN 800
11-14 Standard Bore
Gasket Kit
769cc Top End Gasket Kit. Includes: head, base, cam
chain tensioner, and exhaust gaskets.
0
0
880230 149.95
G
SPORTS-
MAN 800
05-10 Standard Bore
Cylinder Kit
Standard Bore Kit. 10.2:1 comp, 80mm. Includes
(Cylinder, Piston, Rings, Top-End Gaskets). Uses
Vertex #23643.
10.2:1 80
769
880231 695.95
G
SPORTS-
MAN 800
05-10 Standard Bore
HC Cylinder Kit
Standard Bore Hi-Comp Kit. 10.2:1 comp, 80mm.
Includes (Cylinder, Piston, Rings, Top-End Gaskets).
Uses Vertex #23644.
10.2:1 80
769
880232 695.95
G
SPORTS-
MAN 800
11-14 Standard Bore
Cylinder Kit
Standard Bore Kit. 10.2:1 comp, 80mm. Includes
(Cylinder, Piston, Rings, Top-End Gaskets). Uses
Vertex #23643.
10.2:1 80
769
880233 695.95
G
SPORTS-
MAN 800
11-14 Standard Bore
HC Cylinder Kit
Standard Bore Hi-Comp Kit. 12.0:1 comp, 80mm.
Includes (Cylinder, Piston, Rings, Top-End Gaskets).
Uses Vertex #23644.
12.0:1 80
769
880234 695.95
G
SPORTS-
MAN 800
05-10 Big Bore
Gasket Kit
808cc Top End Gasket Kit. Includes (Head, Base,
Chain Tensioner, & Exhaust Gaskets)
0
0
880235 149.95
G
SPORTS-
MAN 800
11-14 Big Bore
Gasket Kit
808cc Top End Gasket Kit. Includes (Head, Base,
Chain Tensioner, & Exhaust Gaskets)
0
0
880236 149.95
G
SPORTS-
MAN 800
05-10 Big Bore Cylin-
der Kit
+2mm Big Bore Kit. 10.2:1 comp, 82mm. Includes
(Cylinder, Piston, Rings, Top-End Gaskets). Uses
Vertex #23645.
10.2:1 82 2.00
808
880237 895.95
G
SPORTS-
MAN 800
11-14 Big Bore Cylin-
der Kit
+2mm Big Bore Kit. 10.2:1 comp, 82mm. Includes
(Cylinder, Piston, Rings, Top-End Gaskets). Uses
Vertex #23645.
10.2:1 82 2.00
808
880238 895.95
G
