VERTEX PISTONS
Type
Version Year Description
Comp.
Ratio
Cyl
Bore
(mm)
Piston
Diam.
(mm)
Disp
Size
Over
STD
Top End
Piston
Kit
Part #
Piston
Kit
Part #
Repl
Ring(s)
Part #
Wrist
Pin
Part #
Circlip
Part #
YAMAHA
CONTINUED
BANSHEE
350
CAST
REPLICA
87-06 Top end piston set includes: pistons, rings, pin,
circlips, top end gaskets, and wrist pin bearings
when applicable.
STD 65.5 65.45 350 1.5
901748
BANSHEE
350
CAST
REPLICA
87-06 Top end piston set includes: pistons, rings, pin,
circlips, top end gaskets, and wrist pin bearings
when applicable.
STD 65 64.95 350
1
901747
BANSHEE
350
CAST
REPLICA
87-06 Top end piston set includes: pistons, rings, pin,
circlips, top end gaskets, and wrist pin bearings
when applicable.
STD 64.75 64.7 350 0.75
901746
BANSHEE
350
CAST
REPLICA
87-06 Top end piston set includes: pistons, rings, pin,
circlips, top end gaskets, and wrist pin bearings
when applicable.
STD 64.5 64.45 350 0.5
901745
BANSHEE
350
CAST
REPLICA
87-06 Top end piston set includes: pistons, rings, pin,
circlips, top end gaskets, and wrist pin bearings
when applicable.
STD 64.25 64.2 350 0.25
901744
BANSHEE
350
CAST
REPLICA
87-06 Top end piston set includes: pistons, rings, pin,
circlips, top end gaskets, and wrist pin bearings
when applicable.
64 63.95 350 STD
901743
BANSHEE
350
CAST
REPLICA
87-06 Replica Piston kit; Kit includes: Piston, rings, pin,
clips
64 63.95 350 STD
901001 901591 901027 901675
BANSHEE
350
CAST
REPLICA
87-06 Replica Piston kit; +0.25mm. Kit includes: Piston,
rings, pin, clips
STD 64.25 64.2 350 0.25
901054 901742 901027 901675
BANSHEE
350
CAST
REPLICA
87-06 Replica Piston kit; +0.50mm. Kit includes: Piston,
rings, pin, clips
STD 64.5 64.45 350 0.5
901055 901121 901027 901675
BANSHEE
350
CAST
REPLICA
87-06 Replica Piston kit; +0.75mm. Kit includes: Piston,
rings, pin, clips
STD 64.75 64.7 350 0.75
901056 901122 901027 901675
BANSHEE
350
CAST
REPLICA
87-06 Replica Piston kit; +1.00mm. Kit includes: Piston,
rings, pin, clips
STD 65 64.95 350
1
901057 901123 901027 901675
BANSHEE
350
CAST
REPLICA
87-06 Replica Piston kit; +1.50mm. Kit includes: Piston,
rings, pin, clips
STD
65.5 65.45 350 1.5
901058 901124 901027 901675
BANSHEE
350
CAST
REPLICA
87-06 Replica Piston kit; +2.00mm. Kit includes: Piston,
rings, pin, clips
STD
66 65.95 350
2
901059 901125 901027 901675
BANSHEE
350
CAST LONG
ROD
87-06 +5mm Long Rod Performance Piston kit; Std bore.
Kit includes: Piston, rings, pin, clips. Must be used
with Hot Rods crank 4011 or 4111
64 63.95 373
901006 901591 901027 901675
BANSHEE
350
CAST LONG
ROD
87-06 +5mm Long Rod Performance Piston kit; +0.50mm
makes 379cc. Kit includes: Piston, rings, pin, clips.
Must be used with Hot Rods crank 4011 or 4111
64.5 64.45 379 0.5
901087 901121 901027 901675
BANSHEE
350
CAST LONG
ROD
87-06 +5mm Long Rod Performance Piston kit; +1.00mm
makes 385cc. Kit includes: Piston, rings, pin, clips.
Must be used with Hot Rods crank 4011 or 4111
65 64.95 385
1
901088 901123 901027 901675
BANSHEE
350
CAST LONG
ROD
87-06 +5mm Long Rod Performance Piston kit; +1.50mm
makes 391cc. Kit includes: Piston, rings, pin, clips.
Must be used with Hot Rods crank 4011 or 4111
65.5 65.45 391 1.5
901089 901124 901027 901675
BANSHEE
350
CAST LONG
ROD
87-06 +5mm Long Rod Performance Piston kit; +2.00mm
makes 397cc. Kit includes: Piston, rings, pin, clips.
Must be used with Hot Rods crank 4011 or 4111
66 65.95 397
2
901090 901125 901027 901675
BANSHEE
350
CAST LONG
ROD
87-06 +5mm Long Rod Performance Piston kit; +2.50mm
makes 403cc. Kit includes: Piston, rings, pin, clips.
Must be used with Hot Rods crank 4011 or 4111
66.5 66.45 403 2.5
901091 901129 901027 901675
BLASTER
200
CAST
REPLICA
88-06 Top end piston kit includes: piston, rings, pins,
circlips, top end gaskets, and wrist pin bearing
when applicable.
66 65.95 195 STD
901757
BLASTER
200
CAST
REPLICA
88-06 Replica Piston kit; Kit includes: Piston, rings, pin,
clip
66 65.95 195 STD
901002 901126 901027 901675
BLASTER
200
CAST
REPLICA
88-06 Replica Piston kit; +0.25mm. Kit includes: Piston,
rings, pin, clip
STD 66.25 66.2 196.5 0.25
901060 901127 901027 901675
BLASTER
200
CAST
REPLICA
88-06 Replica Piston kit; +0.50mm. Kit includes: Piston,
rings, pin, clip
STD 66.5 66.45 198 0.5
901061 901128 901027 901675
BLASTER
200
CAST
REPLICA
88-06 Replica Piston kit; +0.75mm. Kit includes: Piston,
rings, pin, clip
STD
66.75 66.7 199.5 0.75
901062 901130 901027 901675
BLASTER
200
CAST
REPLICA
88-06 Replica Piston kit; +1.00mm. Kit includes: Piston,
rings, pin, clip
STD
67 66.95 201
1
901063 901131 901027 901675
BLASTER
200
CAST
REPLICA
88-06 Replica Piston kit; +1.00mm. Kit includes: Piston,
rings, pin, clip
STD
67.5 67.45 204 1.5
901064 901132 901027 901675
